Air heated gasifier Vaporizer for LO2、LN2、LAr、LNG、LCO2、LC2H4、LPG 50-8000Nm3/h
-
Air heated gasifier Vaporizer is a high-efficiency and energy-saving heat exchange equipment that uses natural convection of air to heat the low-temperature liquid (LNG, LO2, LN2, LAR, lco2, etc.) in the heat exchange pipe to completely evaporate it into gas. Its characteristic is that it does not consume any additional energy (such as electricity, steam or fuel oil). At the same time, it is a new high-efficiency gasification equipment with compact structure, no noise, no pollution, simple operation and convenient maintenance.
Product features:
01. No energy consumption, no pollution, green environmental protection
02. Special aluminum heat exchange, high efficiency, lightweight design and long service life
03. Special Φ 120、 Φ 160、 Φ 200 large diameter special aluminum finned tube, with extremely fast defrosting speed and effective inner fin structure, which greatly improves the heat exchange effect of the heat exchange tube
04. "Bridge" connecting elements are beautiful and generous, and the stress caused by thermal expansion and cold contraction of each part can be eliminated during operation
05. Carry out special anti-oxidation treatment process on the surface of heat exchange tube
06. Optimize the process design to reduce the pressure drop to * * * low, without bias flow, and ensure that the flow rate is controlled within a safe range
07. Advanced high-pressure pipe composite technology makes the pressure pipe fully contact with the heat exchange pipe, ensuring the heat exchange efficiency
08. All gasifiers are cleaned and manufactured in full accordance with oxygen service standards, making them safer to use
09. Design conditions: temperature - 10 ° C, relative temperature 70%, gasification capacity for continuous use for 8-12 hours
10. Applicable media: LO2, LN2, LAR, LNG, lco2, lc2h4, LPG, etc
11. Working pressure: 0.8-35.0mpa
12. Single set flow: 50-8000nm3 / h, and multiple sets can be combined in parallel for greater flow.
